14

 | English

1 609 92A 00R | (12.12.12)

Bosch Power Tools



Use the battery only in conjunction with your Bosch
power tool.

This measure alone protects the battery

against dangerous overload.



Use only original Bosch batteries with the voltage list-
ed on the nameplate of your power tool.

When using oth-

er batteries, e. g. imitations, reconditioned batteries or
other brands, there is danger of injury as well as property
damage through exploding batteries.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for driving in and loosening screws
and bolts as well as for tightening and loosening nuts within
the respective range of dimension.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Tool holder

2

Locking sleeve

3

Carrying strap

4

Belt clip *

5

Battery pack *

6

Battery unlocking button *

7

Rotational direction switch

8

On/Off switch

9

“PowerLight”

10

Handle (insulated gripping surface)

11

Screwdriver bit with ball catch *

12

Universal bit holder *

13

Screwdriver bit *

14

Application tool (e. g. an impact socket) *

15

Carbon brushes

16

Cover lid

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Cordless Impact Screwdriver

GDR 14,4 V-LI

GDR 18 V-LI

Article number

3 601 JA1 4..

3 601 JA1 3..

Rated voltage

V=

14.4

18

No-load speed

min

-1

0 – 2 800

0 – 2 800

Impact rate

min

-1

0 – 3 200

0 – 3 200

Maximum torque, hard screwdriving
application according to ISO 5393

Nm

150*

160*

Bolt size

mm

M6 – M14

M6 – M14

Tool holder

¼" hexagon socket

¼" hexagon socket

Weight according to EPTA-Procedure
01/2003

kg

1.5/1.7*

1.6/1.8*

Cordless Impact Screwdriver

GDS 14,4 V-LI

GDS 18 V-LI

Article number

3 601 JA1 T..

3 601 JA1 S..

Rated voltage

V=

14.4

18

No-load speed

min

-1

0 – 2 800

0 – 2 800

Impact rate

min

-1

0 – 3 200

0 – 3 200

Maximum torque, hard screwdriving
application according to ISO 5393

Nm

170*

180*

Bolt size

mm

M6 – M16

M6 – M16

Tool holder



 ½"



 ½"

Weight according to EPTA-Procedure
01/2003

kg

1.5/1.7*

1.6/1.8*
