For Customers in Europe

For this radio equipment the following

restrictions on putting into service or of

requirements for authorization of use

apply in AT/BE/BG/CY/CZ/DK/EE/FI/FR/

DE/EL/HU/IE/IT/LV/LT/LU/MT/NL/PL/

PT/RO/SK/SI/ES/SE/UK/UK(NI)/HR/IS/LI/

NO/CH/AL/BA/MK/MD/RS/ME/XK/TR:
5 150 - 5 350 MHz band is restricted to

indoor operations only.

IEEE802.11

b/g/n

2 400 MHz

< 60 mW

e.i.r.p.

IEEE802.11

a/n/ac

5 150-5 350 MHz

5 470-5 725 MHz

< 35 mW

e.i.r.p.

IEEE802.11

a/n/ac

5 725-5 850 MHz < 25 mW

e.i.r.p.

Bluetooth 2 400 MHz

< 10 mW

e.i.r.p.

Hereby, Sony Corporation declares that

this equipment is in compliance with

Directive 2014/53/EU.
The full text of the EU declaration of

conformity is available at the following

internet address:
https://compliance.sony.eu

Hereby, Sony Corporation declares that

this equipment is in compliance with the

UK relevant statutory requirements.
The full text of the declaration of

conformity is available at the following

internet address:
https://compliance.sony.co.uk

For Customers in Indonesia

IEEE802.11b/g/n

2 400 MHz

Bluetooth

2 400 MHz

For customers who purchased

their camera from a store in

Japan that caters to tourists

Note

Some certification marks for standards

supported by the camera can be

confirmed on the screen of the camera.
Select MENU



 (Setup)



[Setup Option]



 [Certification Logo].

Specifications

Camera

[System]

Camera Type:

Interchangeable Lens Digital Camera

Lens: Sony E-mount lens

[Image sensor]

Image format: 35 mm full frame

(35.9 mm × 23.9 mm), CMOS image

sensor

Effective pixel number of camera:

Approx. 33 000 000 pixels

Total pixel number of camera:

Approx. 34 100 000 pixels

[Electronic Viewfinder]

Type: 1.3 cm (0.5 type)

Electronic Viewfinder

[Monitor]

7.5 cm (3.0 type) TFT drive, touch

panel

[General]

Rated input: 7.2 V

, 3.8 W

Operating temperature:

0 to 40 °C (32 to 104 °F)

Storage temperature:

–20 to 55 °C (–4 to 131 °F)

Dimensions (W/H/D) (Approx.):

131.3 × 96.4 × 79.8 mm

131.3 × 96.4 × 69.7 mm

(from grip to monitor)

5 1/4 × 3 7/8 × 3 1/4 in.

5 1/4 × 3 7/8 × 2 3/4 in.

(from grip to monitor)

Mass (Approx.):

658 g (1 lb 7.3 oz) (including battery

pack, SD Card)
