8
1. Camera type
35 mm camera with built-in flash
2. Film format
24 x 36 mm
3. Lens
35 mm, f/11
camera to subject distance: 1m - ∞
4. Shutter
mechanical shutter
5. Shutter Speed
1/100 sec.
6. Viewfinder
Reverse Galilean type
7. Flash
Built-in flash, charging time about 8 sec.
8. Range of flash shooting: ISO 100 (1.0m - 1.2m)
ISO 200 (1.0m - 2.8m)
ISO 400 (1.0m - 4.0m)
9. Power source
1 x AA size alkaline battery
10. Dimensions
43x69x117 mm
* Specifications are subject to change without notice.
Turn on the camera by sliding the lens cover/
flash switch (7) to “ ” position as shown in fig-
ure 1.
Turn off the camera by sliding the lens cover/
flash switch (7) to “●” position when it is not in
use.
Loading battery
1. Open the battery cover (14) as shown in fig-
ure 2.
2. Insert one AA size alkaline battery into the
battery compartment according to required
indicators ‘+’ and ‘-’.
Note: Do not use rechargeable Ni-Cd battery.
Loading film
[Use 35 mm negative film with sensitivity of
IS0-100, 200 or 400.]
1. Pull up the rewind crank (3) as shown in fig-
ure 3. Open the back cover (16).
2. Open the back cover (16) by pushing down
the back cover switch (15).
3. Put the film in and press down the rewind
crank to hold the film in position. Pull out
film leader and insert it into the slot of the
film take-up spool (18). Then turn the film
advance wheel (12) to ensure the film being
flat on the body. See figure 5.
4. Close the back cover (16).
OPERATING PROCEDURE
SPECIFICATION
