7

INSTALLATION INSTRUCTIONS

Wall holder model 032.01 - 032.02
032.04 - 032.04/L - 032.05 - 032.05 L

Model 032.01

Standard model with on/off switch


Model 032.02

Model with standard European socket 2P + ear thing 16A and
hairdryer on/off switch


Model 032.04 - 032.04/L - 032.05 - 032.05 L

Model with universal shaver socket and hairdryer on/off switch.
A safety transformer insulates the shaver socket from the
mains and a protection device inhibits the operation of
appliances with a load higher than 20VA.


Installation of wall holder

This work should only be carried out by a suitably qualified
electrical engineer, in order to comply with the existing national
safety regulations. When the spiral cord is extended to its
maximum length, the hairdryer shall not be reached by a person
using the bath or the shower.
There are two possible methods of installation:

A = for fixed connection lead
B = for mobile connection lead


Attention: before installing the hairdryer
always switch off the general switch
of your mains electricity.

Method A (for fixed connection lead) for
wall holder model 032.01 - 032.04
032.04/L - 032.05 - 032.05 L

The connection wiring from the mains for wall holder models
032.01, 032.04, 032.04/L, 032.05, 032.05 L must be type
H05VV-F 2x1,5 mm

2

.

1. Separate the cover (1) of the wall holder from the back plate

by loosening the screw (14).

2. Remove the knockout (2) provided in the back plate of the

wall holder.

3. Feed the mains supply cable (3) coming out of the wall into

the hole in the back plate left after removing the knockout
(2).

4. Secure the back plate of the wall holder to the wall using the

plugs and screws provided.

5. Remove the terminal connector (4), connect the mains

supply cable (3) to the terminal connector (4), as shown

in the picture, and then secure again the terminal
connector (4).

6. Model 032.01, 032.04, 032.04/L, 032.05, 032.05 L are

double insulated and no ear th connection is provided.

7. Fit the front cover of the wall holder, taking care to locate

the cable sleeve (6) properly.

8. Secure the front cover with the screw (14).
9. Switch on the general switch of your mains electricity. The

hairdryer is ready for use.

Method B: (for mobile connection lead)
only for wall holder model 032.01 - 032.02
032.04 - 032.04/L - 032.05 - 032.05 L

The connection wiring from the mains for wall holder models
032.01, 032.04, 032.04/L, 032.05, 032.05 L must be type
H05VV-F 2x1,5 mm

2

.

The connection wiring from the mains for wall holder model
032.02 must be type H05VV-F 3G x 2,5 mm

2

.

1. Separate the cover (1) of the wall holder from the back plate

by loosening the screw (14).

2. Remove the knockout (8) provided in the base of the back

plate of the wall holder for feeding the cable sleeve (11).

3. Secure the back plate of the wall holder to the wall using the

plugs and screws provided.

4. Feed cable sleeve (11) over end of mains cable (13),

remove the terminal connector (9), connect the mains
supply cable (13) to the terminal connector (9), as shown
in the picture, and then secure again the terminal connector
(9). Secure the cable grip (10) with the screws provided.

5. Locate the cable sleeves (6) and (11) in the slot provided in

the base of the back plate.

6. Fit the front cover of the wall holder, taking care to locate

the cable sleeves (6) and (11) properly.

7. Secure the front cover with the screw (14).
8. Switch on the general switch of your mains electricity. The

hairdryer is ready for use.

INSTRUCTIONS FOR USE

Control Switches

Control switch on wall holder 0-1 = Off/On


Hairdryer Mod. 530.02 - 530.15 - 530.22
533.03 - 533.05 - 540.05 - 540.06 - 542.05
and 542.06

Blue pushbutton:

ON = On/Off (pressure must

     be maintained to
     operate the hairdryer)


Slide Switch

Cool = (low power)

1 = (medium power)
2 = (maximum power)

• Allow your appliance to cool before storing away and do not wrap the

supply cord around the hairdryer in storage.

• The A-weighted sound pressure level of the hairdryers for commercial use

is below 70 dB(A).
