INSTALLATION INSTRUCTIONS

Wall holder for hairdryer
Type 036 - 038A - 038B

Type 036

Front housing model.

Type 038A

Ver tical housing model.

Type 038B

As the 038A but with no switch.

Installation of wall holder

This wall holder must only be installed by a qualified electrician
in conformity to applicable safety standards.

The wall holder may be installed in one of two ways:
A = for fixed connection lead
B = for mobile connection lead

Attention: before installing the wall holder always switch off
the general switch of your mains electricity.

For each pole a switch with a minimum break distance between
contacts of 3 mm must be fitted up-line of the appliance.
Each time the appliance is opened, the switch must be used to
disconnect the appliance.
The connection wiring must be type H05VV-F 2x1,5 mm

2

.

Method A

IMPORTANT: Refer to the figures for the model you have
purchased.

1. Unscrew the screw (1) (fig. 1) and remove the cover from the

wall unit.

2. Break the plastic membrane (3) at the back of the wall unit

(fig. 3A).

3. Route the main power cable from the wall (4) through the

hole left by the plastic membrane (3) (fig. 3A).

4. Fix the back of the wall unit to the wall using the fixing screws

and wall plugs provided (fig. 2).

5. Remove the terminal strip (5). The input power cable (4) and

the output power cable (9) of hairdryer with max input current
of 10A,if not already connected, must be connected to the
terminal strip(5).
In mod. 036 the Neutral output cable(9) must be connected
to terminal strip(5) and the Line output cable (9) to terminal
strip (11).

6. Reposition the terminal strip. Tighten the cable clamp

(6 and 10) with its own screws. (fig. 3A). IMPORTANT: This

appliance is double insulated and has no ground (ear th)
connection.

7. Fit the cover back on the wall unit with (1) (fig. 1).
8. Switch the power on at the mains switch. The hair dryer is

now ready to use.

Method B

IMPORTANT: Refer to the figures for the model you have
purchased.

1. Unscrew the screw (1) (fig. 1) and remove the cover from the

wall unit.

2. Break the plastic membrane (7) (fig. 3B).
3. Fix the back of the wall unit to the wall using the fixing screws

and wall plugs provided (fig. 2).

4. Route the input power cable (8) and the output power (9)

into the holes (fig. 3B).

5. Remove the terminal strip (5). The input power cable (8) and

the output power cable (9) of hairdryer with max input current
of 10A,if not already connected, must be connected to the
terminal strip(5).
In mod. 036 the Neutral output cable(9) must be connected
to terminal strip (5) and the Line output cable (9) to terminal
strip (11).
Reposition the terminal strip. Tighten the cable clamp (6 and
10) with its own screws. (fig. 3B). IMPORTANT: This appliance
is double insulated and has no ground (ear th) connection.

6. Fit the cover back on the wall unit with (1) (fig. 1).
7. Switch the power on at the mains switch. The hair dryer is

now ready to use.

INSTRUCTIONS FOR USE

Hairdryer with wall holder

Control Switches

Control switch on wall holder
(only for models equipped with a switch) rif. 2 fig. 1:

0-1 = Off/On

Hairdryer
Type 533.03 - 533.05 - 533.03/I - 533.05/I
542.05 - 542.06 - 542.14 - 561.22

Pushbutton:
ON=On/Off

(pressure must be maintained to operate the hairdryer)

Slide Switch
Cool=(low power)

1=(medium power)
2=(maximum power)

• Remember to check regularly that the air inlet and outlet grills are clean.
• Allow your appliance to cool before storing away and do not wrap the supply

cord around the hairdryer in storage.

• The A-weighted sound pressure level of the hairdryers for commercial use is

below 70 dB(A).
