Maintenance should be carried out by an adult regularly.
Cleaning
Use a soft and wet cloth to clean. Stains hard to remove can be scrubbed with a toothbrush and toothpaste, then wiped o
ff
with a soft and wet cloth.
To prevent jamming to the wheels, wheel bearings, or brakes, please clean and check these areas (as shown in the gray
highlighted areas below) for dirt and other foreign objects.
First clean up the foreign objects, and then wipe clean with a soft wet cloth. Lubricate both sides of the bearing with
lubricating oil or machine oil. If the problem still exists, please contact customer service.
CAUTION:
To avoid the accumulation of foreign objects, DO NOT ride on muddy, dusty, grassy or slippery roads.
Do not clean your scooter with alcohol, gasoline, acetone, or other corrosive/volatile solvents. These substances may
damage the appearance and internal structure of your scooter. Do not wash your scooter with a power washer or hose.
10
09
7 Specifications
8 Maintenance
Battery Type
Nominal Voltage
Lithium-ion battery
21.6 V
Traversable Terrian
Charging time
Approx. 2.5 h
Operating Temperature
Storage Temperature
-4–122°F (-20–50°C); 41–86°F (5–30°C) recommended
IP Rating
14–104°F (-10–40°C)
IPX4
Flat surface, paved road; obstacles < 0.4 in (1 cm); gaps < 1.2 in (3 cm)
Approx. 5 h
Net Weight
Approx. 19.8 lbs (9.0 kg)
Approx. 20.9 lbs (9.5 kg)
Approx. 22.0 lbs (10.0 kg)
Weight and
Size
Battery Pack
Motor
Max. Power
180 W (0.18 kW)
Length × Width × Height
Rider
Requirement
Payload
Recommended Age
Recommended Height
Max. speed
Typical Range
[1]
Nominal Capacity / Energy
Battery Management System Over-heating, short circuit, over-current and over-charge protection
Nominal Power
120 W (0.12 kW)
Charging Temperature
Approx. 31.5 × 13.7 × 35.4 in
(800 × 350 × 900 mm)
Approx. 37.0 × 15.7 × 43.3 in
(940 × 400 × 1100 mm)
Approx. 33.1 × 15.7 × 39.4 in
(840 × 400 × 1000 mm)
3’9”–4’9” (115–145 cm)
4’3”–5’3” (130–160 cm)
Approx. 10 mph (16 km/h)
44–110 lbs (20–50 kg)
6–12 yrs.
8–14 yrs.
4’7”–5’10” (140–180 cm)
10+ yrs.
2500 mAh / 54 Wh
5000 mAh / 108 Wh
Approx. 6.2 miles (10 km)
32–113°F (0–45°C); 50–95°F (10–35°C) recommended
Vehicle
Parameters
150 W (0.15 kW)
260 W (0.26 kW)
Approx. 12.4 miles (20 km)
ZING C8
ZING C10
ZING C20
Item
Battery
Charger
Input Voltage
100—240 V~
Rated Output
Max. Output Voltage
Output Power
24.2 W (0.02 kW)
24.2 V, 1.0 A
25.2 V
Braking Method
Hand-operated brake
Others
Tires
Frame Material
Solid tire; material: synthetic rubber
Steel
Handlebar Material
Food Pad Materia
TPR
Sandpaper
Silicone
1
Wheel bearing
2
[1]Typical Range: tested while riding with a full battery, 110 lbs (50 kg) load, 77°F (25°C), 60% of max. speed on average
on pavement.
* Some of the factors that a
ff
ect range include: rider weight, number of starts and stops, ambient temperature, etc.
