While working, always hold the planer in such a way
that the planer base plate lies flat against the work-
piece.

Otherwise the planer could slip and cause injury.

Products sold in GB only:

Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.

u

Hold the power tool firmly with both hands and make
sure you have a stable footing.

 The power tool can be

more securely guided with both hands.

Product Description and
Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.

Please observe the illustrations at the beginning of this oper-
ating manual.

Intended use

The power tool is intended for planing wood-based materials
such as beams and boards while resting firmly on the work-
piece. It is also suitable for chamfering edges and for rebat-
ing.

Product features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

Cutting depth scale

(2)

Knob for setting the cutting depth (insulated gripping
surface)

(3)

Chip ejector

(4)

Lock-off button for on/off switch

(5)

On/off switch

(6)

Screw for belt cover

(7)

Belt cover

(8)

Planer base plate

(9)

V-grooves

(10)

Star key

(11)

Fastening screw for clamping jaw

(12)

Clamping jaw

(13)

Blade head

(14)

Guide groove for planer blade

(15)

HSS planer blade

(16)

HSS planer blade retaining clip

(17)

Fastening screw for HSS planer blade retaining clip

(18)

Sharpening aid for HSS planer blades

(19)

Setting gauge for HSS planer blades

(20)

HM/TC planer blade

A)

(21)

Parallel guide

(22)

Scale for rebate width

(23)

Locking nut for rebate width setting

(24)

Fastening screw for parallel/angle guide

(25)

Angle guide

A)

(26)

Locking nut for angle setting

A)

(27)

Fastening screw for rebate depth guide

A)

(28)

Rebate depth guide

A)

(29)

Parking rest

(30)

Drive belt

(31)

Large belt wheel

(32)

Small belt wheel

(33)

Handle (insulated gripping surface)

(34)

Adapter for changing from HSS to TC planer blades

A)

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical data

Planer

GHO 6500

Article number

0 601 596 0..

Rated power input

W

650

No-load speed

rpm

16,500

Cutting depth

mm

0–2.6

Rebate depth

mm

0–9

Max. planing width

mm

82

Weight according to EPTA Pro-
cedure 01:2014

kg

2.8

Protection class

/II

The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.

Noise/vibration information

Noise emission values determined according to

EN 62841-2-14

.

Typically, the A-weighted noise level of the power tool is:
Sound pressure level

86

 dB(A); sound power level

97

 dB(A). Uncertainty K =

3

 dB.

Wear hearing protection

Total vibration values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 62841-2-14

:

a

h

 =

5.5

 m/s

2

, K =

1.5

 m/s

2

,

The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure detailed in EN 62841
and may be used to compare power tools. They may also be
