13 ENGLISH

FUNCTIONAL DESCRIPTION

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before adjusting or checking function on the tool.

Installing or removing battery cartridge

CAUTION:

Always switch off the tool before

installing or removing of the battery cartridge.

CAUTION:

Hold the tool and the battery car-

tridge firmly when installing or removing battery

cartridge.

 Failure to hold the tool and the battery

cartridge firmly may cause them to slip off your hands

and result in damage to the tool and battery cartridge

and a personal injury.

►

Fig.3:

1.

 Red indicator

2.

 Button

3.

 Battery cartridge

To remove the battery cartridge, slide it from the tool

while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the

battery cartridge with the groove in the housing and slip

it into place. Insert it all the way until it locks in place

with a little click. If you can see the red indicator on the

upper side of the button, it is not locked completely.

CAUTION:

Always install the battery cartridge

fully until the red indicator cannot be seen.

 If not,

it may accidentally fall out of the tool, causing injury to

you or someone around you.

CAUTION:

Do not install the battery cartridge

forcibly.

 If the cartridge does not slide in easily, it is

not being inserted correctly.

Indicating the remaining battery capacity

Only for battery cartridges with the indicator

►

Fig.4:

1.

 Indicator lamps

2.

 Check button

Press the check button on the battery cartridge to indi-

cate the remaining battery capacity. The indicator lamps

light up for a few seconds.

Indicator lamps

Remaining

capacity

Lighted

Off

Blinking

75% to 100%

50% to 75%

25% to 50%

0% to 25%

Charge the

battery.

The battery

may have

malfunctioned.

NOTE:

 Depending on the conditions of use and the

ambient temperature, the indication may differ slightly

from the actual capacity.

Tool / battery protection system

The tool is equipped with a tool/battery protection sys-

tem. This system automatically cuts off power to the

motor to extend tool and battery life. The tool will auto-

matically stop during operation if the tool or battery is

placed under one of the following conditions:

Overload protection

When the battery is operated in a manner that causes

it to draw an abnormally high current, the tool automati-

cally stops and the main power lamp blinks in green. In

this situation, turn the tool off and stop the application

that caused the tool to become overloaded. Then turn

the tool on to restart.

Overheat protection

When the tool or battery is overheated, the tool stops

automatically and the main power lamp lights up in red.

In this case, let the tool and battery cool before turning

the tool on again.

NOTE:

 In high temperature environment, the over-

heat protection likely to work and the tool stops

automatically.

Overdischarge protection

When the battery capacity is not enough, the tool stops

automatically and the main power lamp blinks in red. In

this case, remove the battery from the tool and charge

the battery.

Main power switch

WARNING:

Always turn off the main power

switch when not in use.

To turn on the tool, press the main power switch until

the main power lamp lights up in green. To turn off,

press the main power switch again.

►

Fig.5:

1.

 Main power lamp

2.

 Main power switch

NOTE:

 The main power lamp blinks in green if the

switch trigger is pulled under unoperatable conditions.

The lamp blinks in one of the following conditions.
•

When you turn on the main power switch while

holding down the lock-off lever and the switch

trigger.

•

When you pull the switch trigger while the chain

brake is applied.

•

When you release the chain brake while holding

down the lock-off lever and pulling the switch

trigger.

NOTE:

 This chain saw employs the auto power-off

function. To avoid unintentional start up, the main

power switch will automatically shut down when the

switch trigger is not pulled for a certain period after

the main power switch is turned on.
