When the log is supported along its entire length, it is cut
from the top (overbuck).
When the log is supported on one end, cut 1/3 the diameter
from the underside (underbuck).
When the log is supported on both ends, cut 1/3 the dia-
meter from the top overbuck. Then make the finished cut by
underbucking the lower 2/3 to meet the first cut.

When bucking on a slope, always stand on the uphill side of
the log. When “cutting through”, release the cutting pressure
near the end of the cut without relaxing your grip on the
chain saw handles in order to maintain complete control.
Don’t let the chain contact the ground. After completing the
cut, wait for the saw chain to stop before you move the chain
saw. Always stop the chain saw motor before moving from
tree to tree.

Troubleshooting

The following chart lists problem symptoms, possible causes and corrective action, if your machine does not operate properly.
If these do not identify and correct the problem, contact your service agent.

u

Warning: Switch off and remove plug from mains be-
fore investigating fault.

Problem

Possible Cause

Corrective Action

Chain saw fails to oper-
ate

Kickback brake is activated

Pull back the activation lever for kickback brake

(4)

 to position

➊

, so that the white dot is on the

"I" symbol.

Plug not connected

Connect plug

Mains socket faulty

Use another socket

Fuse faulty / blown

Replace fuse

Extension cable damaged

Try without extension cable

Chain saw operates in-
termittently

Mains cable defective

Check mains cable and have it replaced, if re-
quired

External or internal wiring defect

Contact your Bosch Service Centre

On/Off switch

(2)

 defective

Contact your Bosch Service Centre

Saw chain dry

No oil in reservoir

Refill oil

Vent in oil filler cap

(14)

 clogged

Clean oil filler cap

(14)

Oil passage clogged

Clean oil passage

Brake does not stop
saw chain

Kickback brake/run-down brake defective

Contact your Bosch Service Centre

Saw chain/guide bar
hot

No oil in reservoir

Refill oil

Vent in oil filler cap

(14)

 clogged

Clean oil filler cap

(14)

Oil passage clogged

Clean oil passage

Chain tension too high

Tension saw chain

Dull saw chain

Sharpen saw chain or replace

Chain saw rips, vi-
brates, does not saw
properly

Chain tension too loose

Tension saw chain

Dull saw chain

Sharpen saw chain or replace

Chain worn out

Replace saw chain

Chain teeth are facing in the wrong direction

Reassemble with chain in correct direction

Maintenance and Cleaning

u

Warning! Switch off and remove plug from mains be-
fore adjusting or cleaning. The same applies when the
mains cable is damaged, cut or entangled.

If the replacement of the supply cord is necessary, this has
to be done by Bosch or an authorized Bosch service agent in
order to avoid a safety hazard.

Note:

 To ensure long and reliable service, carry out the fol-

lowing maintenance regularly.
Regulary check the chain saw for obvious defects such as
loose, dislodged or damaged saw chain and chain bar, loose
fixings and worn or damaged components.
When disassembling the saw chain, take care that the chain
is first loosened with the chain tensioning ring

(11)

. Disas-

sembly of the chain saw without first loosening the saw chain
can damage the chain saw.
