18

 | English

1 609 929 X78 | (25.1.11)

Bosch Power Tools

Assembly

Replacing/Inserting the Saw Blade

f

Before any work on the machine itself, pull
the mains plug.

f

When mounting the saw blade, wear protec-
tive gloves.

Danger of injury when touching

the saw blade.

f

When changing the saw blade, take care
that the saw blade holder is free of material
residue, e. g. wood or metal shavings.

Selecting a Saw Blade

An overview of recommended saw blades can
be found at the beginning of these instructions.
Use only ½" universal shank saw blades. The
saw blade should not be longer than required
for the intended cut.
Use a thin saw blade for narrow curve cuts.

Inserting the Saw Blade (see figure A)

Turn the locking sleeve

4

 approx. 90 °  in the di-

rection of the arrow and hold. Push the saw
blade

1

 into the saw blade holder

3

. Release the

locking sleeve

4

 again.

f

Check the tight seating of the saw blade.

A

loose saw blade can fall out and lead to inju-
ries.

For certain work, the saw blade

1

 can also be

turned through 180 °  (with the teeth pointed up-
wards) and re-inserted again.

Removing the Saw Blade (see figure B)

Turn the locking sleeve

4

 approx. 90 °  in the di-

rection of the arrow and hold. Remove the saw
blade

1

.

Dust/Chip Extraction

f

Dusts from materials such as lead-containing
coatings, some wood types, minerals and
metal can be harmful to one’s health. Touch-
ing or breathing-in the dusts can cause aller-
gic reactions and/or lead to respiratory infec-
tions of the user or bystanders.
Certain dusts, such as oak or beech dust, are
considered as carcinogenic, especially in
connection with wood-treatment additives
(chromate, wood preservative). Materials
containing asbestos may only be worked by
specialists.
– Provide for good ventilation of the work-

ing place.

– It is recommended to wear a P2 filter-

class respirator.

Observe the relevant regulations in your
country for the materials to be worked.

f

Prevent dust accumulation at the work-
place.

Dusts can easily ignite.

Operation

Operating Modes

f

Before any work on the machine itself, pull
the mains plug.

Pivoting and Retractable Footplate
(see figure C)

Due to its movability, the adjustable footplate

2

adapts to the required angular position of the
surface.
Depending on the saw blade being used and the
application, the footplate

2

 can be moved in

lengthway direction in three steps. Press the re-
lease button for the footplate

9

 and slide the

footplate

2

 to the required position. Release the

footplate release button

9

 and check that the

footplate

2

 is firmly latched. Slide the footplate

2

 as required until it is firmly latched.
