16
| English
1 619 P09 555 | (20.7.11)
Bosch Power Tools
Intended Use
The machine is intended for lengthways and crossways cut-
ting of wood with straight cutting lines as well as mitre cuts in
wood while resting firmly on the workpiece. With suitable saw
blades, thin-walled non-ferrous metals, e. g., profiles, can al-
so be sawed.
Working ferrous metals is not permitted.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1
Blade guard
2
Lock-off button for On/Off switch
3
On/Off switch
4
Auxiliary handle (insulated gripping surface)
5
Spindle lock button
6
Scale for mitre angle
7
Wing bolt for parallel guide
8
Wing bolt for bevel-angle preselection
9
Cutting mark, 0 °
10
Cutting mark, 45 °
11
Parallel guide *
12
Retracting blade guard
13
Riving knife (GKS 85 G)
14
Base plate
15
Lever for retracting blade guard
16
Wing bolt for bevel-angle preselection
17
Sawdust ejector
18
Handle (insulated gripping surface)
19
Allen key
20
Clamping bolt with washer
21
Clamping flange
22
Saw blade *
23
Mounting flange
24
Saw spindle
25
Screw for attachment of riving knife (GKS 85 G)
26
Extraction adapter *
27
Fastening screw for extraction adapter (GKS 85) *
28
Clamping lever for cutting-depth preselection
29
Cutting-depth scale
30
Set of screw clamps *
31
Guide rail *
32
Connection piece *
33
Vacuum hose *
* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Circular Saw
GKS 85
Professional
GKS 85 G
Professional
Article number
3 601 E7A 0..
3 601 E7A 9..
Rated power input
W
2 200
2 200
No-load speed
min
-1
5 000
5 000
Rotational speed under load, max.
min
-1
3 500
3 500
Cutting depth, max.
– for 0 ° bevel angle
– for 45 ° bevel angle
mm
mm
85
65
85
65
Spindle lock
z
z
Constant electronic control
–
z
Reduced starting current
z
z
Base plate dimensions
mm
383 x 170
406 x 208
Saw blade diameter, max.
mm
235
235
Saw blade diameter, min.
mm
230
230
Blade thickness, max.
mm
2.2
2.2
Tooth thickness/setting, max.
mm
3.2
3.2
Tooth thickness/setting, min.
mm
2.0
2.0
Mounting bore
mm
30
30
Weight according to EPTA-Procedure 01/2003
kg
7.5
7.8
Protection class
/
II
/
II
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
OBJ_BUCH-293-006.book Page 16 Wednesday, July 20, 2011 4:24 PM
