 | English

1 609 92A 089 | (12.4.13)

Bosch Power Tools

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

On/Off switch

2

Lock-off button for On/Off switch

3

Thumbwheel for speed preselection  (GKS 65 GCE)

4

Auxiliary handle (insulated gripping surface)

5

Spindle lock button

6

Scale for mitre angle

7

Wing bolt for parallel guide

8

Clamping lever for bevel-angle preselection

9

Cutting mark, 0 °

10

Cutting mark, 45 °

11

Parallel guide *

12

Retracting blade guard

13

Base plate

14

Lever for retracting blade guard

15

Sawdust ejector

16

Blade guard

17

Handle (insulated gripping surface)

18

Allen key

19

Clamping bolt with washer

20

Clamping flange

21

Saw blade *

22

Mounting flange

23

Saw spindle

24

Fastening screw for extraction adapter *

25

Extraction adapter *

26

Clamping lever for cutting-depth preselection

27

Cutting-depth scale

28

Wing bolt for bevel-angle preselection

29

Set of screw clamps *

30

Guide rail *

31

Connection piece *

32

Vacuum hose *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Noise/Vibration Information

Measured sound values determined according to EN 60745.

Typically the A-weighted noise levels of the product are:
Sound pressure level 92 dB(A); Sound power level
103 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:
Cutting wood: a

h

= 3.0 m/s

2

, K = 1.5 m/s

2

,

Cutting metal: a

h

= 5.0 m/s

2

, K = 1.5 m/s

2

.

The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
24.01.2013

Technical Data

Dr. Egbert Schneider
Senior Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9

Circular Saw

GKS 65

GKS 65 G

GKS 65 GCE

Article number

3 601 F67 0..

3 601 F68 9..

3 601 F68 9..

Rated power input

W

1 600

1 600

1 800

No-load speed

min

-1

5 900

5 900

2 300 – 5 000

Rotational speed under load, max.

min

-1

4 200

4 200

1 400 – 4 000
