18
| English
1 609 929 J94 • 6.11.06
Functional Description
Read all safety warnings and all
instructions.
Failure to follow the warn-
ings and instructions may result in elec-
tric shock, fire and/or serious injury.
While reading the operating instructions, unfold the
graphics page for the machine and leave it open.
Intended Use
The power tool is intended for cutting wood length-
ways and crossways in straight lines and at bevel
angles of up to 45 ° on a firm surface.
Product Features
The numbering of the product features refers to the
illustration of the machine on the graphics page.
1
On/Off switch
2
Lock-off button for On/Off switch
3
Auxiliary handle
4
Spindle lock button
5
Scale for mitre angle
6
Allen key
7
Wing bolt for bevel-angle preselection
8
Wing bolt for parallel guide
9
Cutting mark, 45 °
10
Cutting mark, 0 °
11
Parallel guide
12
Retracting blade guard
13
Riving knife
14
Base plate
15
Wing bolt for bevel-angle preselection
16
Sawdust ejector
17
Blade guard
18
Clamping bolt with washer
19
Clamping flange
20
Saw blade*
21
Mounting flange
22
Saw spindle
23
Screw for attachment of riving knife
24
Clamping lever for cutting-depth preselection
25
Cutting-depth scale
26
Set of screw clamps*
27
Extraction adapter
28
Guide-rail adapter*
29
Guide rail *
30
Connection piece*
31
Vacuum hose *
* The accessories illustrated or described are not
included as standard delivery.
Technical Data
Noise/Vibration Information
Measured values determined according to
EN 60745.
Typically the A-weighted noise level of the machine is:
sound pressure level 95 dB(A); sound power level
106 dB(A). Uncertainty K = 3 dB.
Wear hearing protection!
Overall vibrational value (vector sum of three direc-
tions) determined according to EN 60745:
Vibrational emission value a
h
= < 2.5 m/s
2
, uncer-
tainty K = 1.5 m/s
2
.
The vibration emission level given in
this information sheet has been
measured in accordance with a standardised test
given in EN 60 745 and may be used to compare one
tool with another.
The vibration emission level will vary because of the
ways in which a power tool can be used and may
increase above the level given in this information
sheet. This could lead to a significant underestimate
of exposure when the tool is used regularly in such a
way.
Circular Saw
GKS 160
PROFESSIONAL
Article number
3 601 F70 0..
Rated power input
W
1 050
No-load speed
rpm
5 600
Rotational speed under
load, max.
rpm
4 000
Riving knife thickness,
max.
mm
1.8
Cutting depth, max.
– for 0 ° bevel angle
– for 45 ° bevel angle
mm
mm
54
38
Spindle lock
z
Base plate dimensions
mm
146 x 290
Saw blade diameter, max.
mm
160
Saw blade diameter, min.
mm
150
Blade thickness, max.
mm
1.7
Tooth thickness/setting,
max.
mm
2.6
Tooth thickness/setting,
min.
mm
2.0
Mounting bore
mm
20
Weight according to
EPTA-Procedure
01/2003
kg
3.6
Protection class
/
II
The values given are valid for nominal voltages [U] of
230/240 V. For lower voltage and models for specific coun-
tries, these values can vary.
Please observe the article number on the type plate of your
machine. The trade names of the individual machines may
vary.
WARNING
