Philips HQ 6071/16 - Инструкция по эксплуатации - Страница 2

 1

 Put the appliance plug in the shaver (Fig. 6).

 2

 Put the adapter in the wall socket.

 3

 When the battery is fully charged, remove

the adapter from the wall socket and pull the

appliance plug out of the shaver.

Cordless shaving time

A fully charged shaver has a cordless shaving time

of up to 40 minutes.

Using the appliance
shaving

 1

 Press the on/off button once to switch on

the shaver.

The light ring lights up.

 2

 Move the shaving heads quickly over your

skin, making both straight and circular

movements (Fig. 7).

Shaving on a dr y face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philips shaving system.

 3

 Press the on/off button once to switch on

the shaver.

 4

 To prevent damage to the shaving unit, put

the protection cap on the shaver after every

use (‘click’) (Fig. 8).

Trimming

For grooming sideburns and moustache.

 1

 Open the trimmer by pushing the slide

upwards (Fig. 9).

The trimmer can be activated while the motor

is running.

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

The easiest and most hygienic way to clean the

appliance is to rinse the shaving unit and the hair

chamber with hot water ever y time you have used

the appliance.

For thorough cleaning of the shaving heads, we

advise you to use Philips Shaving Head Cleaning

Spray HQ110.

Every day: shaving unit and hair

chamber

Warning: Remove the detachable cord from the

handheld part before cleaning this part in water.

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

 1

 Switch off the shaver, remove the adapter

from the wall socket and pull the appliance

plug out of the shaver.

 2

 Press the release button (1) and open the

shaving unit (2) (Fig. 10).

 3

 Clean the shaving unit and the hair chamber

by rinsing them under a hot tap for some

time (Fig. 11).

Make sure the inside of the shaving unit and the

hair chamber have been cleaned properly.

 4

 Rinse the outside of the appliance (Fig. 12).

 5

 Close the shaving unit and shake off

excess water.

Never dry the shaving unit with a towel or tissue,

as this may damage the shaving heads.

 6

 Open the shaving unit again and leave it open

to let the appliance dry completely (Fig. 13).

You can also clean the hair chamber without water

by using the brush supplied.

Every six months: shaving heads

 1

 Open the shaving unit.

You can also pull the shaving unit off the shaver for

easier cleaning.

 2

 Turn the wheel anticlockwise (1) and remove

the retaining frame (2). Then take out the

shaving heads (Fig. 14).

 3

 Clean the cutters and guards with the brush

supplied (your shaving heads may differ from

the one shown in the figure) (Fig. 15).

Do not clean more than one cutter and guard

at a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it

may take several weeks before optimal shaving

performance is restored.

 4

 Put the shaving heads back into the shaving unit.

Put the retaining frame back into the shaving

unit and turn the lock clockwise (Fig. 16).

Note: If you removed the shaving unit from the

shaver, reattach it. First insert the hinge of the shaving

unit into the slot in the rim of the hair chamber and

then push the shaving unit home until it locks into

place (‘click’).  (Fig. 17)

 5

 Close the shaving unit.

Trimmer

Clean the trimmer ever y time you have used it.

 1

 Switch off the shaver, remove the adapter

from the wall socket and pull the appliance

plug out of the shaver.

 2

 Clean the trimmer with the brush

supplied (Fig. 18).

 3

 Lubricate the trimmer teeth with a drop of

sewing machine oil every six months (Fig. 19).

storage

 - To prevent damage to the shaving unit, put the

protection cap on the shaver (‘click’) (Fig. 8).

Replacement

To maintain optimal shaving results, replace the

shaving heads ever y two years.

Replace damaged or worn shaving heads with

HQ8 Precise Cutting System Shaving Heads.

 1

 Switch off the shaver, remove the adapter

from the wall socket and pull the appliance

plug out of the shaver.

 2

 Open the shaving unit.

You can also pull the shaving unit off the shaver.

 3

 Turn the wheel anticlockwise (1) and remove

the retaining frame (2). Then take out the

shaving heads (Fig. 14).

 4

 Put the new shaving heads in the shaving unit.

Put the retaining frame back into the shaving

unit and turn the lock clockwise.  (Fig. 16)

Note: If you removed the shaving unit from the

shaver, reattach it. First insert the hinge of the shaving

unit into the slot in the rim of the hair chamber and

then push the shaving unit home until it locks into

place (‘click’).  (Fig. 17)

 5

 Close the shaving unit.

Ordering accessories

To retain the top performance of your shaver,

make sure you clean it regularly and replace its

shaving heads at the recommended time.

To purchase accessories for your shaver,

please visit our online shop at

www.shop.philips.com/service

. If the online

shop is not available in your countr y, go to your

Philips dealer or a Philips ser vice centre. If you have

any difficulties obtaining accessories for your shaver,

please contact the Philips Consumer Care Centre

in your countr y. You find its contact details in the

worldwide guarantee leaflet.

shaving heads

 - We advise you to replace your shaving

heads ever y two years. Always replace with

the appropriate shaving heads for your type

of shaver (Fig. 20).

Cleaning

 - Use Cleaning Spray HQ110 to clean the

shaving heads thoroughly.

Accessories available for this shaver

HQ8 Precise Cutting System Shaving Heads.

HQ8505 powerplug.

HQ110 Philips Shaving Head Cleaning Spray.

Environment

 - Do not throw away the appliance with the

normal household waste at the end of its life,

but hand it in at an official collection point for

recycling. By doing this, you help to preser ve

the environment (Fig. 21).

 - The built-in rechargeable shaver battery contains

substances that may pollute the environment.

Always remove the battery before you discard

and hand in the shaver at an official collection

point. Dispose of the battery at an official

collection point for batteries. If you have trouble

removing the battery, you can also take the shaver

to a Philips service centre. The staff of this centre

will remove the battery for you and will dispose

of it in an environmentally safe way (Fig. 22).

Disposal of the battery

Only remove the battery if it is completely empty.

 1

 Remove the adapter from the wall socket and

pull the appliance plug out of the shaver.

 2

 Let the shaver run until it stops, undo the

screws and open the shaver (Fig. 23).

 3

 Remove the battery.

Do not connect the shaver to the mains again

after the battery has been removed.

guarantee and service

If you need information or if you have a

problem, please visit the Philips website at

www.philips.com/support

 or contact the Philips

Consumer Care Centre in your country. You find its

phone number in the worldwide guarantee leaflet. If

there is no Consumer Care Centre in your country,

go to your local Philips dealer.

guarantee restrictions

The shaving heads (cutters and guards) are

not covered by the terms of the international

guarantee because they are subject to wear.
