REPLACING OVEN LAMP
WARNING:

To  avoid  electric  shock,  ensure  that  the  appliance  circuit  is

open before changing the lamp. (having circuit open means power is off)

First disconnect the power of appliance and en-
sure that appliance is cold.
Remove the glass protection by turning as
indicated in the figure on the left side. If you
have difficulty in turning, then using plastic
gloves will help you in turning.
Then remove the lamp by turning, install the
new lamp with same specifications. Lamp
specifications must be as follows;
-220-240 V 50/60 Hz AC, -15 W, -Type E14
Reinstall glass protection, plug the power cable
of appliance into electrical socket and complete
replacement. Now you can use your oven.

CLEANING OVEN GLASS

Lift  by  pressing  on  plastic  latches  on  left  and  right  side  as  shown  in

Figure 13 and pulling the profile toward yourself as in Figure 14. Glass

is  released  after  profile  is  removed  as  shown  in  Figure  15.  Remove  the

released  glass  by  pulling  toward  yourself  carefully.  Outer  glass  is  fixed

to  oven  door  profile.  You  can  perform  glass  cleaning  easily  after  glasses

are  released.  You  can  mount  glasses  back  by  performing  the  operations

reversely after cleaning and maintenance are completed. Ensure that pro-

file is seated properly in place.

Figure 11

Figure 12

Figure 13

Figure 14

Figure 15
