19

REPLACING OVEN LAMP
WARNING:

To avoid electric shock, ensure that the appliance circuit is

open before changing the lamp. (having circuit open means power is off)

First disconnect the power of appliance and ensure that appliance is cold.

Remove the glass protection by turning as  indicated in the figure on

the left side. If you have difficulty in turning, then using plastic gloves

will help you in turning.

Then remove the lamp by turning, install the new lamp with same

specifications.

Reinstall glass protection, plug the power cable of appliance into electrical

socket and complete replacement. Now you can use your oven.

Type G9 Lamp Assembly:                           Type E14 Lamp Assembly:

CLEANING OVEN GLASS

Lift by pressing on plastic latches on left and right side as shown in

Figure 13 and pulling the profile toward yourself as in Figure 14. Glass

is  released  after  profile  is  removed  as  shown  in  Figure  15.  Remove  the

released  glass  by  pulling  toward  yourself  carefully.  Outer  glass  is  fixed

to  oven  door  profile.  You  can  perform  glass  cleaning  easily  after  glasses

are released. You can mount glasses back by performing the operations

reversely after cleaning and maintenance are completed. Ensure that

profile is seated properly in place.

220-240 V, AC
15-25 W

Figure 11

220-240 V, AC
15 W

Figure 12

Figure 13

Figure 14

Figure 15

GB
