15

ENGLISH

TECHNICAL PASSPORT

Electric oven

T E C H N I CA L  I N F O R M AT I O N

If the equipment does not work,

please contact the Technical Service
Department and advise them of the
problem, indicating:

1 Serial number (S-No)
2 Appliance model. (Model)

You will find this information on the

rating plate on the lower part of the
oven when the door is opened.

  The item that you have bought

meets the European directives on
electrical material safety (73/23/CEE)
and electromagnetic com

patibility

(89/336/CEE).

AENOR  certifies  the  aptitude  of

this appliance for the function and
guarantees the truthful ness of all data
shown in the energy card.

I N S TA L L AT I O N

This information is intended for the

installer, as the person responsible for
assembly and electrical connection.
If you install the oven yourself,
the manufacturer will not be held
responsible for any possible damage.

Before Installation. Comments

Â

To unpack the oven, pull the

tab located on the lower part of the
box and to move it, hold by the lateral
handles and never by the oven door
handle.

Â

A niche is required in the kitchen

unit as per the dimensions shown on

the figure, providing a minimum depth

of 550 mm. (See technical drawings on
the page 14).

Â

To  fit  multifunction  ovens  in

their locations, the back part of the
unit corresponding to the shaded area
of technical drawings, must not have
any projections (reinforcements, pipes,
sockets, etc). (See the page 14).

Â

The adhesive used for the plastic

covering of kitchen furniture must be
able to withstand temperatures up to
85°C.

Electrical Connection. Legal
Requirements

The installer must check that:

Â

The voltage and cycles of the mains

supply correspond to that indicated on the
rating plate.

Â

The electrical installation can stand

the maximum power indicated on the rating
plate.

Â

The connection diagram is shown in

the following figure.

Â

The electrical connection has

adequate earthing in accordance with
regulations in force.

Â

The connection must be carried out

with an omnipolar switch, of an adequate
size for the current drawn. There must be
a minimum aperture between contacts of
3 mm to enable disconnection in the case
of emergency, cleaning or bulb exchange.
Under no circumstances must the earth wire
pass through this switch.

After connecting the electricity, check that

all the electrical parts of the oven are working.
