www.dahuasecurity.com
DHI-VTO4202F-P
Modular Outdoor Station
·
Modules make the device with great expansibility
·
Anodized front aluminum panel; IK07
·
Supports voice and video communication
·
2 MP high definition fisheye camera with 160° view range
·
Access control function; controls two locks
·
Compatible with 2-wire interface and RJ45 interface
·
Surface mount and flush mount
·
IP65 (Apply silica gel to gaps between the device and the wall. Liquid
sodium silicate is recommended. For details, see the quick start guide.)
Technical Specification
Model
DHI-VTO4202F-P
System
Main Processor
SoC processor
Operating System
Embedded Linux operation system
Network Protocol
IPv4, RTSP, RTP, TCP, UDP, SIP, P2P
Basic
Camera
CMOS Low illumination 2MP HD colorful 160° fisheye
camera
Angle of View
H:160°, V:82°, D:180°
Focal Length
1.95 mm
WDR
WDR
Noise Reduction
Noise suppression and echo cancellation
Video Encoding
H.264
Frame Rate
PAL: 25 fps; NTSC: 30 fps
Video Bit Rate
256K to 2M
Light Compensation
IR light
Day/Night Switch
Yes
Audio Encoding
PCM G.711 A G.711 U
Audio Input
Built-in omnidirectional microphone
Audio Output
Built-in loudspeaker
Audio Bit Rate
16Khz 16bit
Function
Communication
Methods
Digital communication
Unlock Mode
Remote unlocking
Auto Snapshot
Yes
Leave Videos or Text
Messages
Yes
Web Configuration
Yes
VTO4 Series
|
DHI-VTO4202F-P
Performance
Housing Material
Aluminum
Port
RS-485 Port
1 RS-485 half-duplex port
Alarm Output Port
1
Power Output Port
1-ch 12 VDC output 100mA
Unlock Button
Exit button for opening the door
Door Status Detection
Detects door magnetic status
Door Lock Control
NC/COM/NO
Ethernet Port
10/100 Mbps self-adaptive Ethernet/2-wire
Alarm
Tamper Alarm
Tamper alarm
Regular
Ingress Protection
IP65 (Apply silica gel to gaps between the device and the
wall. Liquid sodium silicate is recommended. For details, see
the quick start guide.)
Appearance Color
Silver
Housing Material
Aluminum
Power Supply Mode
12 VDC/2-Wire IP Inteface/PoE
Installation Method
Surface mount and flush mount
Accessory
Mounting box
Dimensions
100mm×100mm×49.30mm (3.94"×3.94"×1.94")
Protection Grade
IK07, IP65 (Apply silica gel to gaps between the device and
the wall. Liquid sodium silicate is recommended. For details,
see the quick start guide.)
Working Temperature
-20°C to +60°C (-4°F to +140°F )
Working Humidity
10%RH–90%RH
Power Consumption
≤12W
Net Weight
0.35kg (0.77 lb)
Gross Weight
0.4kg (0.88 lb)
IP65
