6

Descale filter

 ................................................................................................................... removable

Auto-off ................................................................................................................................ available

Boil-dry shut-off ................................................................................................................ available

Disc heating element

 ....................................................................................................... available

Inner illumination ............................................................................................................. available

Rotation on the base................................................................................................................ 360º

Power cord storage

 ........................................................................................................... available

Power cord length

 ................................................................................................................ 0.65 m

Overall dimensions ...................................................................................

224 × 156 × 238 mm

Net weight

 .....................................................................................................................

1.2 kg ± 3%

Package includes

Electric kettle ........................................... 1 pc.

Kettle base ................................................ 1 pc.

User manual ............................................. 1 pc.

Service booklet ........................................ 1 pc.

In accordance with the policy of continuous improvement, the manufacturer reserves

the right to make any modifications to design, packaging arrangement, or technical

specifications of the product without prior notice.

Model configuration

A1

1.

Glass  housing  with

water level graduated

scale

2.

Descale filter

3.  Lid

4.  Lid release button

5.  Handle

6.  I/0 button

7.  Base with recess for

cable

8.  Power cord

I.      P R I O R TO  F I R S T  U S E

Carefully take the appliance and its detachable parts out of the package.

Remove all wrapping materials and stickers except for the serial number identification

sticker.
After the appliance transportation or storage at low temperature keep it at room

temperature for at least two hours before plugging in.

Wipe the base of the appliance with a damp cloth, then let it dry. You may notice foreign

smell when using the appliance for the first time. This does not mean its malfunction.

You are advised to boil water in the kettle a few times before the first use to get foreign smell

out and disinfect the appliance.

I I.      O P E RAT I N G  T H E  A P P L I A N C E

1.

Fix the kettle with the base to the solid even dry horizontal surface. Ensure the

escaping  steam  does  not  fall  on  wallpaper,  decorative  coats,  electric  units  and

other items, which can be damaged by steam and high temperature.

2.

Unwind  the  power  cord  to  the  desired  length.  Put  the  excessive  part  into  the

compartment located on the base bottom. If necessary use the extender of a

suitable power (no less than 2.5 kW).

3.  Remove the kettle from the base. Press the lid release button.

4.  Pour water into the kettle, water level should be between the MIN and MAX points

on the scale. If water level is higher than MAX point, the boiling water may be

splashed. In case of water undersupply the appliance may be switched off in advance.

ATTENTION! The unit is meant only for water heating and boiling.

5.

Close the kettle lid, press the lock button and set the kettle to the base. The ap

-

pliance will be operated only if it is properly fixed.

6.  Ensure that the kettle is off (I/0 button is in 0 position).

7.

Plug in the appliance.

8.  Move I/0 button in I position. Blue inner illumination will be on, the appliance

will start operating.

9.

After water comes to a boil indication will go out. The appliance will switch to

the standby mode.

10.  To switch off the appliance move I/0 button in 0 position.

CAUTION! In case you take the kettle off the base without switching it off, inner illu-

mination will be off, while I/0 button will remain in I position. The kettle will resume

operation once you have placed it on the base. You are advised to switch off the appli-

ance every time you take it off pressing I/0 button in 0 position.

11.

Once you have finished, unplug the device.

Safety system

•

The kettle is supplied with an automatic shut-off system upon boiling.

•

In case of water shortage the automatic overheat protection turns off the kettle.

Wait till the appliance is cooled, thereafter it will be ready for operation.

I I I.       C L E A N I N G  A N D  M A I N T E N A N C E

CAUTION! Before cleaning the kettle or the kettle base unplug the appliance, drain

water and let the unit cool down.

Regularly clean the kettle housing and wipe the base with a damp cloth. Let the kettle

and kettle base dry thoroughly before use.
