CORE REACTOR 850 GOLD
CORE REACTOR 750 GOLD
CORE REACTOR 650 GOLD
Installation
Safety and Agency Approvals
5
7
9
11
12
EN
Product Specifications
CONGRATULATIONS ON THE PURCHASE OF YOUR NEW
XPG CORE REACTOR GOLD SERIES POWER SUPPLIES
XPG Core Reactor Gold Series power supplies are created for silence with extreme power
performance, designed with a 120mm cooling fan featuring extremely low RPM fan control
circuit design allows the fan to operate efficiently and silently. 80 PLUS
Gold rated efficiency ensures low-cost operation and the fully modular cable set provides
user convenience and easy builds. XPG Core Reactor Gold uses high quality 105°C
Japanese capacitors throughout and is a great choice for a high performance PC.
SAFETY AND PROTECTION
The main outputs will be latched off when each protection is triggered. The main
output can be reset by cycling the DC remote on/off or AC power. +5Vsb output is auto
recovery when fault condition is removed.
INTEGRATED PROTECTION CIRCUITS
Over Current Protection :
XPG has followed Intel Power Supply Design Guide with 110%-140% of total current
on all+12V & +5V & +3.3V rails. Therefore OCP of XPG Core Reactor is more effective.
Over Voltage Protection :
OVP on +12V, +5V, +3.3V DC outputs rails are required to comply with the latest Intel ATX
Power Supply Design Guide. OVP shuts down the PSU in the event that the DC outputs
exceed a set level, determined by the PSU manufacturer. The minimum voltage levels
required for compliance is +12V rail@ 15.6V max , +5V rail at 7.0V max, +3.3V rail
at 4.5V max.
Over Power Protection :
XPG has followed Intel ATX Power Supply Design Guide with 110-150% of PSU Total
Wattage.
Over Temperature Protection :
OTP ensures that the PSU will shut down when the PSU internal temperature reaches a set
point. This is usually as a result of internal current over loading or a defect fan.
No Load Operation :
XPG has followed Intel ATX Power Supply Design Guide with 0A minimum loading to
support Intel Haswell C6/C7 sleep mode function.
Short Circuit Protection :
SCP is defined as any output impedance of less than 0.1ohms. Amongst other things, SCP
ensures that the PSU shuts down should the +12V, +5V & +3.3V rails short to any ground,
or any other rail. It also ensures that no damage should occur to your PC components if
there is any short circuit inside the system.
XPG Power Supplies have full protection circuits on board to keep your expensive
components safe under all circumstances.
04
03
