05

Short circuit placed on +5V,+12V,+3.3V,-12V will latch off. +5VSB will auto-recovery.

4.2.4 Short Circuit Protection

Current protection should be designed to limit the current to operate within safe operating
conditions. Over current protection schemes where only the voltage output that experiences the
over current event is shut off may be adequate to maintain safe operation of the power supply
and the system; however, damage to the motherboard or other system components may occur.
The recommended over current protection scheme is for the power supply to latch into the
shutdown state. The setting of over current protection for each output rail is as following.

4.2.5 Over-Current Protection

5.1 No Load Start

5.2 Cold Start

When power is applied to SX700-G,SX650-G and SX500-G with no load connected or under minimum
load connected, neither damage to power supply nor hazards to users will occur.

The power supply shall operate properly when first applied at normal input voltage and or so maximum
load after 4 hours storage in 0

℃

 environment.

5. Start Stability

6.1 Temperature and Humidity

6.1.1 Operating

6.2 Altitude

The power supply can operate normally at any altitude between 0 to 10000 feet.

6.3 Vibration and Shock

Sweep and resonance search for each of X,Y,Z, axis at the sweep.

RATE of 1/OCTAVE/Min.

Temperature

0 to 40 oC

Relative Humidity

20 to 90 %

6.1.2 Storage

Temperature

-40 to 70 oC

Relative Humidity

20 to 95 % noncondensing

6. Environments

7. Conducted EMI

5-55-10 Hz

30 minutes

0.35 mm

Frequency

Duration

Amplitude
