2.3.1. PWR_OK (Power Good Signal)

PWR_OK is a “power good” signal. It will be asserted high by the power supply
to indicate that the +5V output is above the under voltage threshold listed in
Table 2. of Section 2.2. PWR_OK will be de-asserted to a low state when
+5V output voltage falls below under voltage threshold, or when AC power has
been removed for a time sufficiently such that power supply operation cannot
work normally. The electrical and timing characteristics of the PWR_OK signal
are given in Table 10. and in figure 1.

2.3.2. PS_ON (DC Soft Start)

PS_ON# is an active-low, TTL-compatible signal that allows a motherboard to
remotely control the power supply in conjunction with features such as soft on/off,
Wake on LAN*, or wake-on-modem. When PS_ON# is pulled to TTL low,
the power supply should turn on the four main DC output rails: +12 VDC, +5 VDC,
+3.3 VDC, and -12 VDC. When PS_ON# is pulled to TTL high or open-circuited,
the DC output rails should not deliver current and should be held at zero
potential with respect to ground. PS_ON# has no effect on the +5VSB output,
which is always enabled whenever the AC power is present. Table 11 lists
PS_ON signal characteristics.

Signal type

+5V TTL compatible

Logic level low

< 0.4 V while sinking 4 mA

Logic level high

Between 2.4 V and 5 V output while sourcing 200

μ

A

High-state output impedance

1 k

Ω

 from output to common

      Max Ripple/Noise

400 mV p-p

Table 10. PWR_OK Signal Characteristics

Parameter

Description

Value

Required

Recommended for

Alternative Sleep Mode

T0 AC

power

on

time

<2s

T1 Power-on

time

<

150ms

T2 Rise

time  0.2

–

20

ms

T3

PWR_OK delay

100 – 150 ms

T4

PWR_OK rise time

< 10 ms

T5

AC loss to PWR_OK hold-up time

> 12 ms

80% load

T6

PWR_OK inactive to DC loss delay

> 1 ms
