8

EN

m

Spatula

n

Juicer funnel

o

Sieve

p

Sieve bracket

q

Juicer housing

Using quick select program

To use a quick select program:
You can turn the

rotary knob

 to select the program

you need and press the knob to confirm your

selection.

-Smoothie
-Ice crushing
-Sauce
-Dessert
-Nut-butter
-Soup

You can directly press the button below for:

-  Clear juice button

 :

juice fruit/vegetable

with little fiber.

-

Pulpy

juice button

 : juice fruit/vegetable

with fiber.

-

 Pulse  button

 : to blend briefly.

-

 Return  button

: press it to stop ongoing

operation and return to selection mode

To use manually

:

Select a quick select program to operate the blender

in manual mode and adjust processing speed by

rotating the knob.
You can adjust processing speed from speed 1 to

speed 12 (maximum speed).

3  Before first time use

Before you use the appliance and accessories for the

first time, thoroughly clean the parts that come into

contact with food. (Fig. 7)

4  Important notes

Stop and unplug the appliance if there is a pungent

smell or smoke. Let it cool down for 15 minutes.

Do not add excessive ingredients. Otherwise, the

ingredient mixture will become too thick or too heavy

to process.

To avoid overloading the appliance, you can

•

Add more liquid ingredient

•

Process in several small batches

•

Use a higher speed setting

Built-in safety lock

This feature ensures that you can only switch on the

appliance if the blender jar, the mill or the tumbler is

assembled on the motor unit properly. If the blender

jar or the tumbler is correctly assembled, the built-in

safety lock will be unlocked.

Safety Feature

This blender is fitted with a safety feature which

safeguards against excessive loads. In case of

overloading, the blender automatically activates

the protection and operation will stop and the

overloading symbol

E01

 will light up on the

control panel. If this occurs, press and hold the rotary

knob for 2 seconds to power off the appliance, unplug

it and allow it to cool down for 15 minutes. Remove

the ingredients and clear up the blender jar before

starting operation.

Electromagnetic fields (EMF)

This Philips appliance complies with all applicable

standards and regulations regarding exposure to

electromagnetic fields.

Recycling

This symbol means that electrical products shall

not be disposed of with normal household

waste. (Fig. 4)
Follow your country’s rules for the separate

collection of electrical products.

2  Overview (Fig. 1)

a

Measuring cup

b

Lid of the blender jar

c

Blender jar

d

Rotary knob and quick select programs:

-

Rotary knob

:

Power on/off the appliance

: press the

rotary

knob

 to power on, press and hold it for 2

seconds to power off the unit.

Wake up the appliance

: press the

rotary knob

to wake up the appliance when it is in standby

mode. (The appliance goes to standby mode

when it is idle for three minutes.)

- Use a quick select program

:

See ”

Using quick select program

” for details.

e

Motor unit

f

Tumbler lid (Optional or HR3770/1x)

g

Tumbler seal ring (Optional or HR3770/1x)

h

Tumbler jar (Optional or HR3770/1x)

i

Seal ring (Optional or HR3770/1x)

j

Blade unit (Optional or HR3770/1x)

k

Blade unit holder (Optional or HR3770/1x)

l

Mill (Optional)
